High quality Yanmar engine with stable performance. More power, low fuel consumption. Using world advanced reliable engine, high efficiency, low vibration, low noise, ensuring enough power output, can be used in all environments, engine is easy to be started even in the coldest climate. Adopting big power YANMAR TNV direct injection diesel engine, green emission, with high power output.
Based on matching technology of excellent engine and a fully imported hydraulic system, our excavators have more power output and improve working speed and helps to reduce fuel consumption.
Main Dimensions Overall Dimension (L x W x H): 5830 x 2150 x 2600mm. Total Length Of Track: 2750mm. Platform Ground Clearance: 720mm. Chassis Width: 2150mm. Track Height: 650mm.
Operating Range Digging Depth: 4015mm, Max. Digging Height: 7050mm Max. Dumping Height: 5188mm Max. Max Digging Radius: 6540mm. Bucket Digging Force 58KN. Arm Digging Force: 40KN.
Hydraulic System Germany REXROTH hydraulic system. Hydraulic Tank Capacity: 85L. Hydraulic Flow: 151.2L/min. Main Safety Valve Pressure MPa: 24.5. Swing System Pressure MPa: 23. Fuel Tank Capacity: 110L. Hydraulic Pump: Hengli. Hydraulic Valve: Husco. Swing Motor: Eaton. Traveling Motor: Eaton.
