EMED EM1.8 EXCAVATOR YANMAR ENGINE & EXPANDABLE TRACKS + FREE ATTACHMENTS

Description

Mini crawler, pilot controls. Specifications: Operating weight: 1700kg. Digging bucket capacity: 0.045cbm/200kg. Digging bucket width: 420mm. Engine: Yanmar 3TNV74F. Rated power: 13.7kw/18.4hp/2200/r/min. Displacement: 0.854L. Bore stroke: Three-cylinder, water cool. Main pump: KDK hydraulic. Valve: Permco. Displacement: 6.8ml/r. Swing motor: USA Eaton. Traveling motor: Korea Donghyun. Main Dimensions: Overall (LxWxH): 3160 x 990 (1140) x 2377mm. Total length of track on land: 1450mm. Platform ground clearance: 473mm. Platform back turning radius: 740mm. Chassis width: 1240mm. Track width: 230mm. Chassis ground clearance: 132mm. Track height: 360mm. Operating Range: Max digging depth: 2150mm. Max vertical digging depth: 1740mm. Max digging height: 3275mm. Max dumping height: 2310mm. Max digging radius on ground: 3610mm. Min rotation radius: 1580mm.
